Advanced Piping Systems manufactures large-diameter short PE100 pipe end caps engineered for an equivalent pressure rating to pipe class. Because each cap's design is critical, it's made thicker than the matching pipe wall thickness and over-engineered to handle water hammer, temperature variance and pressure spikes — so the line end performs as reliably as the pipe itself.

Key features of Pipe End Caps

PE100 / HDPE construction, butt-weld ready for a fully fused, leak-free line end
Over-engineered wall thickness for pressure rating equivalent to pipe class, with margin for water hammer and pressure spikes
SDR11: available from 20mm to 1200mm
SDR17: available from 280mm to 1600mm

PE100 pipe end caps can be used for far more than capping off a line. Fitted on top of an inverted reducing or equal tee, an end cap creates an air trap that removes the small bubbles that form and reduces pipeline performance. We manufacture these air traps with a threaded 1" or 2" port with a ball valve and a dual-acting air release valve. Or with a 3" or 4" flanged air release valve for larger-diameter pipelines.

We also offer end caps with threaded sockets for filling and draining your pipeline, making testing and servicing easy.

Applications

Suited to water, mining, industrial and civil pipelines wherever a strong, pressure-rated line end, air trap, or fill/drain point is required.

We hold stock for fast delivery and back every fitting with expert advice. Talk to our team about end caps, air traps or custom configurations for your pipeline on 1300 362 229.
